Features and  Functions

  • A total of 2000 selectable UHF Frequencies  Can be used in 1000 different locations simultaneously without being mutually interfered.
  • Instant  MUTE  ON/OFF helps singers to avoid feedback from speakers.
  • Comes with 4 Microphones.
  • Transmitting power of the microphone can be adjusted Low/High to avoid feedback.
  • Crystal Lock for each synchronized Frequency (Avoid Frequency slippage).
  • When microphone is not in use  for 5 minutes, it will enter into energy-saving mode. When not in use for 15 minutes, it will be automatically powered off.
  • Infrared (IR) Synchronization Technique for quick Frequency pairing.
  • Operating distance 300 feet.
  • LED Screen Display with the transmitter data.
  • Professional Audio Output: Balanced XLR and Unbalanced 1/4” Jack.
  • Dual Voltage: AC110V-220V.
  • Professional Custom-Made Aluminum Case.





Professional 2000UHF

Wireless Microphone System

Model No. PWM-2024 & PWM4-2024

Operational Manual

(Front Panel of Wireless Microphone Receiver)

1.Microphone Volume Adjustment

Press button “Vol+” to increase and button “Vol-” to decrease the volume of the microphone

2.To change Frequency

       A  To select your preferred Frequency

  • Turn on the Wireless Microphone
  • Press and hold Δ on the Receiver until the number under  CH  (PWM-2024) or CHAN (PWM4-2024)
  • To change and select your preferred Frequency by pressing Δ or  ∇ until the number under CH  (PWM-2024) / CHAN (PWM4-2024) stops flashing.
  • Press button “SET” to your selected Frequency and the “IR……” on the window will flash.
  • Pair the window of the Wireless Microphone to the IR sensor on the right hand side of the front panel of the Receiver.
  • If paired, the Frequency number of the Wireless Microphone and the number of Receiver should be the same.

        B  Pair to a Randomly-selected Frequency

  • Turn on the Wireless Microphone
  • Press and hold ∇ on the Receiver and the Receiver will start randomly selecting a Frequency for you.
  • Press button “SET” to the scanned Frequency and the “IR……” on the window will flash.
  • Pair the window of the wireless microphone to the IR sensor on the right hand side of the front panel of the Receiver.
